Orbea Avant H60 Orange Candy-Cosmic Bronze

RIDING WITHIN REACH

Grab your Avant and fill your bottles before rolling out on your afternoon ride. No other machine can better help you enjoy the exhilaration of road cycling. The speed, freedom and the views offered by quiet roads are all included free with every Avant - and you love it.

AVANT CARBON FORK

The carbon layup and shaping of the Avant fork offers the best combination of elasticity, tire clearance and torsional stiffness. The fork legs sport integrated fender mounts and ample tire clearance for even more versatility.

HIGH POLISH

The new Avant receives the same level of design attention as our carbon frames - The tubes are butted and hydroformed with smooth, polished welds to match the dramatic look of the monocoque frame.

ICR PLUS

Internal Cable Routing is carefully guided along the best path under the stem and through the head tube, with no rub or rattle, and is optimised for both traditional and electronic shifting systems. Proprietary headset spacers smooth airflow and offer easy adjustment.

Specifications:

• FRAME: ORBEA AVANT HYDRO DISC, HYDROFORMED TRIPLE BUTTED ALUMINIUM, HS 1,5" ICR, BB 68MM – BSC ENGLISH, THRU AXLE 12X142MM REAR, THREAD M12X2 P1, INTERNAL CABLE ROUTING, SP 27,2MM, MMS SYSTEM.
• FORK: ORBEA CARBON FORK 2021, 1-1/8" - 1,5" TAPPERED HEAD TUBE COMPATIBLE, THRU AXLE 12X100MM, THREAD M12X2 P1, SPEED RELEASE COMPATIBLE DROPOUT.
• CRANKSET: SHIMANO CLARIS R2000 34X50T
• HEADSET: ACROS ALLOY 1-1/2" INTERNAL CABLE ROUTING
• HANDLEBAR: OC ROAD PERFORNACE RP31-R, RISE 15, REACH 70, DROP 125
• STEM: OC ROAD PERFORMANCE RP21, -6º
• SHIFTERS: SHIMANO CLARIS ST-R2000
• BRAKES: JAGWIRE RIDEREVER MECHANICAL DISC
• CASSETTE: SHIMANO HG50 11-32T 8-SPEED
• REAR DERAILLEUR: SHIMANO CLARIS RD-R2000-GS
• FRONT DERAILLEUR: SHIMANO CLARIS FD-R2000-F
• CHAIN: KMC X8
• WHEELS: ALLOY, TUBELESS, 700C, 19C, 28H
• TYRES: VITTORIA ZAFIRO V RIGID BEAD 700X28C
• SEATPOST: ALLOY, 27.2MM, SETBACK 20
• SADDLE: FIZIK ALIANTE R5
