Introducing Helix, the new standard in performance footwear.

Bont Cycling’s race-proven anatomic fit is now even further enhanced by a newly reimagined closure system. Experience performance and comfort without compromise like never before.

Features

Durolite - has been developed and chosen for the Helix upper for its extremely durable nature and light weight.

Retention System - Continuous wiring spreads the load for a secure hold withoutlocalised pressure points.

Cable Routing - Wraps around and under the rigid carbon chassis for a wide, even anchor point.

Single Boa - The single Boa dial simplifies operation for quick and easy on-the-fly adjustments.

Unidirectional Carbon Chassis - The Helix continues with its unidirectional monocoque chassis in matt finish and is upgraded with an improved grid to assist cleat adjustment.

TPU Toe Protector - Not only protects the front area of the shoe from wheel rub and impact, but also houses ventilation holes for improving airflow through the shoe.

Ventilation - The Helix is highly ventilated with integrated air vents on the front bumper providing direct airflow into the shoe along with perforated upper and tongue to maximise breathability.

Anti Stretch - Between the outer leather and the liner we add a material that is proprietary to Bont to stop the cycling shoe from stretching over time. This layer assits in pedalling efficiency by maintaining a supportive structure over the top of the foot in the upward part of the pedal stroke.

Last Design - A last is a replica of a foot that the cycling shoe is built around. Last makers do not make cycling shoe lasts, they only make shoe lasts so perfecting a cycling shoe last requires a great deal of expertise in functional biomechanics and ongoing research.

Carbon Fiber - The base of the Helix is made by hand utilizing uni-directional carbon fiber which is embedded with epoxy thermo setting resin. The Helix utilizes unidirectional carbon fiber allowing Bont to create a performance cycling shoe with very specific strength characteristics based on stress points in cycling. As unidirectional carbon absorbs less resin then cross weave fibers, it also assists in the weight reduction of the cycling shoes.

Padding - The Helix utilises closed cell memory foam that will not retain water assisting in maintaining a lighter shoe during wet conditions as well as ensuring sweat which can begin to break down the durability of the shoe is not absorbed.

Medial Longitudinal Arch Support - Structural medial longitudinal arch support is provided in all models to stop over pronation of feet. Over pronation is one of the main contributors to incorrect tracking of knees during a cyclists pedaling phase due to internal rotation of tibia and femur. This can result in knee injuries. In addition, the rotation of tibia/femur can cause the pelvis to tilt resulting in lower back strain.

Anatomical Forefoot Shape - Bont cycling shoes anatomical shaping allows the foot to function in its most efficient and anatomically correct position. The foot is supported in its endeavour to relax through the metatarsal joints allowing the pedalling force to be spread across the greatest possible surface area.

Anatomical Heel Cup - The anatomical heel cup shaping of Bont cycling shoes provides increased stability during the pull through stage of pedaling stroke and up stroke. This stabilization is achieved without any mechanical operation or over tightening of straps/laces allowing for increased comfort and blood circulation.

Lateral Forefoot Support - Bont’s lateral forefoot support ensures neutral positioning of the forefoot and alleviates common issues associated with over pronation and supination. These issues often result in incorrect tracking of knees causing injuries along with hip and lower back pain.

Specifications

Model Helix
Material Unidirectional Carbon Monocoque Chassis with Durolite upper
Stack Height 3.6 mm
Air Vents Ventilation via air vents on front bumper and perforated upper
Innersole EVA thermo-moldable
Sole Guards Replaceable
Padding Memory Foam
Cleat Mounting MM grid plus grip / 3 Hole Look Configuration
Fit Customisation Fully Heat Moldable Chassis utilizing Epoxy Thermoset Resin
Closing Options BOA IP1 Dual Dial Retention System with Kevlar wiring
Weight 230g


Size Guide

To find your size, place a piece of paper on a flat surface and place it directly up against a wall. Stand on the paper and ensure you have a 1mm gap between your heel and the wall. Plant your foot firmly on the ground and slowly roll your weight forward and onto the forefoot. For the most effective longest toe measurement, your heel should lift off the ground slight. Look down and take the measurement from the wall edge of the paper to your longest toe. Record the length. With your foot still in place, mark the widest points of the inner and outer edges of your feet. Measure the width across the widest part of your foot and record the number in millimeters. Repeat this step for both feet.

Once the measurements have been taken, use the Foot Length Range on the size chart to find your size. The Last Length measurements shown on the chart are the exact length of the last that we use to build the shoes. This correlates to the precise internal measurement of the shoe.

Following selection of your size in EU or USA, move downward to select the most appropriate width. We recommend adding 1mm to find the most appropriate width. For example, you are looking at a Vaypor S and have determined your best shoe size is 45 and your feet measure 105mm (left) and 107mm (right) wide, with an additional 1mm added, you would still fit within the Standard Range. If your feet measure wide than 109/110mm (size 45/10.5) you should consider Wide fit.

Bont Cycling EU 36 37 38 39 40 40.5 41 42 42.5 43 44 44.5 45 46 46.5 47 48 49 50
Bont Cycling USA 4 4.5 5 6 6.5 7 7.5 8 8.5 9 9.5 10 10.5 11 11.5 12 12.5 13 14
Last Length 225 230 235 240 245 250 255 260 265 270 275 280 285 290 295 300 305 310 315
Foot Length Range 216-220 221-225 226-230 231-235 236-240 241-245 246-250 251-255 256-260 261-265 266-270 271-275 276-280 281-285 286-290 291-295 296-300 301-305 306-310
Narrow Range 81-83 82-84 83-96 84-87 86-88 87-90 88-91 90-92 91-93 92-95 93-96 95-97 96-99 97-100 99-101 100-103 101-104 103-105 104-106
Standard Range 84-93 85-94 87-95 88-97 89-98 91-100 92-102 93-103 94-105 96-106 97-107 98-108 100-110 101-111 102-113 104-114 105-116 106-117 107-119
Wide Range 94-97 95-98 96-100 98-101 99-103 101-104 103-106 104-107 106-109 107-110 108-112 109-113 111-115 112-116 113-118 115-119 117-121 117-121 120-124
Double Wide Range 98-102 99-103 101-105 102-106 104-108 105-110 107-111 108-113 110-115 111-116 113-118 114-119 116-121 117-122 119-124 120-125 122-127 122-127 125-130


Important: ​Be advised all measurements shown in the size chart above are listed in millimetres and refer to all current models purchased after 2015. For customers looking to replace shoes purchased prior to 2015, please refer to our sizing chart to find the most accurate size.
