*Images For Display Purposes Only. See Specs For Full Build Details*
Designed to defy the wind, the Colnago Y1Rs is the ultimate expression of aerodynamic efficiency.
This bike is built to deliver optimal performance in the fastest races, combining advanced technologies and innovative design for sprinters and breakaway specialists.
With a design that drastically reduces air resistance, stiffness optimized for the most powerful sprints, and surprising comfort for long distances, the Y1Rs offers the perfect balance of performance, efficiency, and control.
Cutting-Edge Aerodynamics
The Y1Rs reduces its frontal area by 19% compared to the V4Rs, thanks to innovations like the CC.Y1 handlebars with WYND© technology and the curved downtube. These elements reduce drag and optimize airflow in all wind conditions.
Stiff Where It Matters
The frame structure is designed to provide 3.5% greater stiffness than the previous model. This ensures immediate power transfer during the most intense sprints and unparalleled responsiveness.
Wind Tunnel-Verified Results
Tests conducted in real-world configurations show that the Y1Rs requires 20 fewer watts than the V4Rs to maintain a speed of 50 km/h. A significant advantage in fast races and windy conditions.
Modern Compatibility and Integrated Design
The Y1Rs is compatible with the most advanced electronic groupsets and offers a fully integrated design, from custom bottle cages to the aerodynamic seatpost. Every detail has been optimized to reduce weight and enhance aesthetics.
Wind Tunnel-Verified Results
Tests conducted in real-world configurations show that the Y1Rs requires 20 fewer watts than the V4Rs to maintain a speed of 50 km/h. A significant advantage in fast races and windy conditions.
Modern Compatibility and Integrated Design
The Y1Rs is compatible with the most advanced electronic groupsets and offers a fully integrated design, from custom bottle cages to the aerodynamic seatpost. Every detail has been optimized to reduce weight and enhance aesthetics.
Integrated bottle cages
Standard bottles are not aerodynamic. However, they are the lightest and most practical solution both in races and in training. Colnago designed custom bottle cages to perfectly match the shape of the frame, minimizing the aerodynamic loss due to the bottles. Everything at a competitive weight and within UCI constraints. The downtube bottle cage also features support for a Di2 battery in the downtube, further easing mounting and maintenance.
Please note that the specifications supplied by the manufacturer may be impacted by component stock availability at the factory assembly stage.
This bike will be shipped un-built in the manufacturer supplied packaging. We strongly recommend that this bike be assembled by a qualified bike mechanic or bike shop.
Any assembly undertaken without professional assistance, and subsequent damage from faulty assembly, is at the customers risk.
Specifications
- Details
- Series: R Series
- Model: Y1Rs
- Weight: Size M - Dura Ace - Enve 4.5 : 7.2kg without pedals
- Weight limit: This model has an overall maximum limit (combined weight of bicycle, rider and load) of 110 kg
- Frame kit
- Frame (material): Colnago Y1Rs carbon frame
- Fork (material, section notes): Bayonet fork for disc brakes, integrated cables
- Headset: CeramicSpeed SLT Treated Bearings
- Seatpost: Carbon seatpost 15mm offset
- Through axles: Diameter: 12 mm. length 100 mm (front) - 142 mm (rear)
- Drivetrain
- Shifting system: Shimano Ultegra R8170 Di2 Disc
- Front derailleur: Shimano Ultegra FD-R8150
- Rear derailleur: Shimano Ultegra RD-R8170
- Chain: Shimano CN-M8100 12 Speed
- Cassette: Shimano Ultegra R8100 11-30 / Shimano Ultegra R8100 11-34
- Crankset: Shimano Ultegra R8100 Small: 165mm 52/36 Medium: 165mm 52/36 Large / X-Large: 170mm 52/36
- Bottom bracket: CeramicSpeed BB Alpha BSA (Threaded)
- Brakes
- Brakes: Shimano Ultegra R8170
- Disc size: 160 mm Front / 140 mm Rear - RT-CL800 rotors
- Brake lever: Shimano Ultegra R8170
- Brake caliper: Standard Flat Mount
- Wheels
- Wheels: Enve Pro 4.5 White Decals
- Material: Carbon
- Rim height: Front: 49mm Rear: 55mm
- Internal channel width: 23.5mm
- Hubs: Enve innerdrive premium straight pull hubs
- Through axles: Front: 12-100mm - Rear: 12-142mm
- Tyres: Continental GP5000 S TR 30mm
- Tubes: Tubolito Tubo 80mm 700 x 18-32mm
- Maximum tyre size: 32 mm
- Components
- Saddle: Selle Italia SLR Carbon Superflow Carbon Rail L3 Large
- Handlebar / Stem: Colnago CC.Y1 Integrated Cockpit: Small: 105 - 377 - 400 Medium: 115 - 377 - 400 Large / X-Large: 125 - 397 - 420
- Handlebar Tape: Colnago Grip Black
- Bottle cage: Y1RS Bottle Cages (x2) Colnago x Elite Bottle
Once you purchase, our Customer Service team will contact you within one business day to confirm your desired Crankset length, chainring size, cassette size and bar and stem length and width.
