We were told to win the race, be quick, efficient, keep the pace. Always chasing, seeking more, even if it makes you sore? Letting go of time, habits and doubt. Letting go of all, no rushing about. This bike's made for journeys under the sun. Together and beyond, everyone can come. Ride far and choose those endless views, until you lose.
Features
- All mounting points for your adventure: How much luggage do you want to take along on your bikepacking tour? The ATLAS answers with a resounding ‘yes’. It is approved for a system weight of 135 kg. But that's not all: the luggage and storage options of the ATLAS don't stop at mere mounting points.
- Prep pocket & Prep Pack: For that little bit of extra storage or as a compartment for essentials: the down tube of the 8. series contains a spacious, rattle-free storage compartment – the Prep Pocket.
- Tubeless-Ready System: All ATLAS models are tubeless-ready and come with 45 mm wide tyres. If you want to ride tubeless, all you have to do is remove the inner tubes, install the valves, fill with sealant, and you're ready to go. The 8.9 is delivered directly without inner tubes, with valves fitted and sealant included.
- Premium-Look: OK, this point isn't essential, but with levelled welds (putty) on the 6. series and the clean C.I.S. stem with integrated cable routing on all models, your bike simply looks chic. In addition, the paintwork on every ATLAS 8.9 is hand-painted, making each of these frames truly unique.
- Tyre Clearance: The maximum tyre clearance on the fork is 53 mm. The rear wheel can fit tyres up to 48 mm wide for the 6. series and 45 mm wide for the 8. series.
- Bye Bye Boost: We probably don't need to say much here. Road Boost is a thing of the past. All new ATLAS models come with the well-known 12x100/12x142 axle dimensions and BSA bottom bracket – for easier maintenance.
Specifications
- Frame: Carbon technologie, disc, 142x12 mm thru axle, flat mount 160 mm
- Special Features: Prep Pocket & Prep Pack
- Fork: Carbon technologie, disc, 142x12 mm thru axle, flat mount 160 mm
- Shifter: SRAM Rival E1
- Rear derailleur: SRAM Rival E1 XPLR AXS, 13-speed
- Cassette: SRAM XG-1351 XPLR, 10-46T
- Chain: SRAM Rival E1
- Crankset: SRAM Rival E1, 40 T
- Bottom bracket: Sram, BSA DUB
- Handlebar: Zipp Service Course SL 70 XPLR, alloy, 70 mm, 115 mm, 5° with 11° drop outsweep
- Stem: FOCUS C.I.S. 2.0 integrated, -8°, with alloy Garmin / Wahoo-Mount
- Headset: ACROS IS52 /IS52 (ICR), FOCUS C.I.S. Integrated
- Saddle: fi'zi:k Ridon X5
- Seatpost: Carbon, 27,2 mm, set-back: 11mm
- Brakes front | rear: SRAM Rival E1 | SRAM Rival E1
- Disc brake rotors: SRAM HS2, front: 180 mm (Size L-XL), 160 mm (Size XS-M) / rear: 160 mm
- Wheelset: Zipp 303 XPLR S, carbon, rim height: 54 mm, width: 32-622
- Tyres front | rear: Schwalbe G-One R Pro, super race, tubeless ready, 45-622 | Schwalbe G-One R Pro, super race, tubeless ready, 45-622
- Weight: 8.6 kg (-)
- Permissible system weight: 135 kg
