Race-inspired speed, all-road performance, built for the everyday ride.
The RS7 blends aerodynamic efficiency with everyday rideability.
Its performance-oriented geometry and refined carbon construction deliver speed when you push, while maintaining the comfort and stability needed for longer rides.
Equally at home on weekend training routes or daily commutes, the RS7 offers a balanced performance platform that riders return to again and again.
Carbon Confidence, Every Day
The RS7 is the road bike that makes true performance feel approachable for all riders, boasting full carbon responsiveness, drop-bar control, and a geometry that’s ready for everything from country roads to your fastest group ride.
Topography-Inspired Colorways
Inspired by the contours of iconic mountain terrains, RS7’s finishes aren’t just paint; they’re a nod to the roads that shape riders and the climbs that define seasons.
Making Upgrades Simply Standard
With a Branta alloy crankset featuring a built-in power meter and Find My connectivity, RS7 delivers the upgrades riders usually pay extra for, all baked in from day one.
Key Features
- Branta C45 Base carbon wheelset
- Shimano 105 groupset
- Aero carbon seatpost
- Full carbon frame and fork | Full bike 8.49 kg
Technical Specifications
- FRAME
- XDS Carbon Frame, Toray T-700
- FORK
- XDS Carbon Fork, Toray T-700, 100x12mm Thru-axle
- HANDLEBAR / STEM
- Branta Carbon Integrated
- SEATPOST
- XDS Carbon Seatpost, Aero Profile
- REAR DERAILLEUR
- Shimano 105 RD-R7100
- FRONT DERAILLEUR
- Shimano 105 FD-R7100
- SHIFTERS
- Shimano 105 ST-R7120
- BRAKES
- Shimano 105 BR-R7170
- CASSETTE
- CS-R9012, 12-Speed, 11-34T
- CRANKSET
- Branta Alloy Power Meter Crankset, 52-36T,
- 24mm Steel Spindle, Apply Find My Anti-Theft Technology
- BOTTOM BRACKET
- BSA 24mm
- ROTORS
- Shimano SM-RT70, F:160mm R:160mm
- CHAIN
- SUMC SX12
- WHEELSET
- Branta C45 Base Carbon Wheelset, Stainless Steel Spokes
- TIRES
- Branta R332, 700x32C, 60TPI
- SADDLE
- Branta R302, Steel Rails
- WEIGHT
- 8.49 kg / 18.67 lbs (Size L)
Product images are for illustrative purposes only and may not reflect the exact specifications of the item supplied.
Specifications, features, and availability are subject to change without notice due to manufacturer updates and component availability.
Geometry & Dimensions
Basic Geometry (XS / S / M / L / XL / XXL)
- Seat Tube Length: 420mm 440mm 470mm 490mm 510mm 530mm
- Top Tube Length: 500mm 515mm 531mm 550mm 570mm 590mm
- Head Tube Length: 130mm 135mm 145mm 160mm 175mm 200mm
- Seat Tube Angle: 75° 75° 75° 74° 74° 74°
- Head Tube Angle: 70° 72° 73° 73° 73° 74°
- Chainstay: 410mm 410mm 410mm 410mm 410mm 410mm
- Wheelbase: 973mm 976mm 982mm 993mm 1006mm 1016mm
- Bottom Bracket Drop: 72mm 72mm 70mm 70mm 68mm 68mm
- Stack: 526mm 535mm 546mm 561mm 574mm 602mm
- Reach: 360mm 370mm 380mm 390mm 400mm 412mm
- Front Center: 574mm 577mm 581mm 593mm 606mm 616mm
- Stand Over: 737mm 752mm 772mm 789mm 807mm 830mm
Component Geometry (XS / S / M / L / XL / XXL)
- Fork Rake/Offset: 55mm 55mm 45mm 45mm 45mm 45mm
- Trail: 65mm 58mm 62mm 60mm 58mm 52mm
- Handlebar: 360mm 360mm 380mm 380mm 400mm 400mm
- Stem: 90mm 100mm 110mm 110mm 120mm 120mm
- Crankset: 165mm 165mm 170mm 170mm 172.5mm 172.5mm
- Seat Post: 300mm 300mm 350mm 350mm 400mm 400mm
